For 2014-2023 Ford Transit Connect Trailer Hitch + Wiring 4 Pin Fits All Models Curt 13167 56218 2 inch Tow Receiver

For 2014-2023 Ford Transit Connect Trailer Hitch + Wiring 4 Pin Fits All Models Curt 13167 56218 2 inch Tow Receiver
For 2014-2023 Ford Transit Connect Trailer Hitch + Wiring 4 Pin Fits All Models Curt 13167 56218 2 inch Tow Receiver
For 2014-2023 Ford Transit Connect Trailer Hitch + Wiring 4 Pin Fits All Models Curt 13167 56218 2 inch Tow Receiver
For 2014-2023 Ford Transit Connect Trailer Hitch + Wiring 4 Pin Fits All Models Curt 13167 56218 2 inch Tow Receiver
For 2014-2023 Ford Transit Connect Trailer Hitch + Wiring 4 Pin Fits All Models Curt 13167 56218 2 inch Tow Receiver
For 2014-2023 Ford Transit Connect Trailer Hitch + Wiring 4 Pin Fits All Models Curt 13167 56218 2 inch Tow Receiver
For 2014-2023 Ford Transit Connect Trailer Hitch + Wiring 4 Pin Fits All Models Curt 13167 56218 2 inch Tow Receiver
For 2014-2023 Ford Transit Connect Trailer Hitch + Wiring 4 Pin Fits All Models Curt 13167 56218 2 inch Tow Receiver
For 2014-2023 Ford Transit Connect Trailer Hitch + Wiring 4 Pin Fits All Models Curt 13167 56218 2 inch Tow Receiver
For 2014-2023 Ford Transit Connect Trailer Hitch + Wiring 4 Pin Fits All Models Curt 13167 56218 2 inch Tow Receiver
For 2014-2023 Ford Transit Connect Trailer Hitch + Wiring 4 Pin Fits All Models Curt 13167 56218 2 inch Tow Receiver
For 2014-2023 Ford Transit Connect Trailer Hitch + Wiring 4 Pin Fits All Models Curt 13167 56218 2 inch Tow Receiver
For 2014-2023 Ford Transit Connect Trailer Hitch + Wiring 4 Pin Fits All Models Curt 13167 56218 2 inch Tow Receiver
For 2014-2023 Ford Transit Connect Trailer Hitch + Wiring 4 Pin Fits All Models Curt 13167 56218 2 inch Tow Receiver
For 2014-2023 Ford Transit Connect Trailer Hitch + Wiring 4 Pin Fits All Models Curt 13167 56218 2 inch Tow Receiver
For 2014-2023 Ford Transit Connect Trailer Hitch + Wiring 4 Pin Fits All Models Curt 13167 56218 2 inch Tow Receiver
For 2014-2023 Ford Transit Connect Trailer Hitch + Wiring 4 Pin Fits All Models Curt 13167 56218 2 inch Tow Receiver
For 2014-2023 Ford Transit Connect Trailer Hitch + Wiring 4 Pin Fits All Models Curt 13167 56218 2 inch Tow Receiver
For 2014-2023 Ford Transit Connect Trailer Hitch + Wiring 4 Pin Fits All Models Curt 13167 56218 2 inch Tow Receiver
For 2014-2023 Ford Transit Connect Trailer Hitch + Wiring 4 Pin Fits All Models Curt 13167 56218 2 inch Tow Receiver
For 2014-2023 Ford Transit Connect Trailer Hitch + Wiring 4 Pin Fits All Models Curt 13167 56218 2 inch Tow Receiver
For 2014-2023 Ford Transit Connect Trailer Hitch + Wiring 4 Pin Fits All Models Curt 13167 56218 2 inch Tow Receiver
For 2014-2023 Ford Transit Connect Trailer Hitch + Wiring 4 Pin Fits All Models Curt 13167 56218 2 inch Tow Receiver
For 2014-2023 Ford Transit Connect Trailer Hitch + Wiring 4 Pin Fits All Models Curt 13167 56218 2 inch Tow Receiver
For 2014-2023 Ford Transit Connect Trailer Hitch + Wiring 4 Pin Fits All Models Curt 13167 56218 2 inch Tow Receiver
For 2014-2023 Ford Transit Connect Trailer Hitch + Wiring 4 Pin Fits All Models Curt 13167 56218 2 inch Tow Receiver
For 2014-2023 Ford Transit Connect Trailer Hitch + Wiring 4 Pin Fits All Models Curt 13167 56218 2 inch Tow Receiver
For 2014-2023 Ford Transit Connect Trailer Hitch + Wiring 4 Pin Fits All Models Curt 13167 56218 2 inch Tow Receiver
For 2014-2023 Ford Transit Connect Trailer Hitch + Wiring 4 Pin Fits All Models Curt 13167 56218 2 inch Tow Receiver
For 2014-2023 Ford Transit Connect Trailer Hitch + Wiring 4 Pin Fits All Models Curt 13167 56218 2 inch Tow Receiver
For 2014-2023 Ford Transit Connect Trailer Hitch + Wiring 4 Pin Fits All Models Curt 13167 56218 2 inch Tow Receiver
For 2014-2023 Ford Transit Connect Trailer Hitch + Wiring 4 Pin Fits All Models Curt 13167 56218 2 inch Tow Receiver
For 2014-2023 Ford Transit Connect Trailer Hitch + Wiring 4 Pin Fits All Models Curt 13167 56218 2 inch Tow Receiver
$302.17
  • Stock: In Stock
  • Brand: Curt
  • Model: 13167 56218-CH1834

Applies to this product only

This Trailer Tow Hitch + 4-Flat Fits The Following Vehicles:

2014 - 2023 Ford Transit Connect All Models


This Trailer Tow Hitch + 4-Flat Includes the Following Parts:

  • Class 3 Trailer Hitch, 2" Receiver (Easy Bolt-On, No Drilling)
  • Custom Wiring Harness, 4-Way Flat Output (Plug & Play)
  • Installation instructions, schematics, diagrams, and hardware (if required).

List of Fitment Years:

2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023


CURT 13167 Class 3 Trailer Hitch, 2-Inch Receiver

Manufactured by: Curt

Whatever your task at hand -- whether it's launching that boat before daybreak, setting up your camper before the rush or getting a final load to the dump before close -- CURT class 3 trailer hitches offer the strength needed for serious towing They make it easy to hitch up and Bring It, offering a vehicle-specific fit and the weight capacity to handle a variety of trailers Custom class 3 hitches are the most common type of receiver hitch for pickup trucks and SUVs.

Because of their weight range, they are also found on full-size cars, crossovers and minivans Each custom-fit class 3 hitch package is made for vehicle-specific mounting This particular kit fits certain years of the Ford Transit Connect (see application info to verify vehicle compatibility).

It provides a weight carrying capacity of 3,500 lbs GTW and 525 lbs TW.

It is also compatible with a weight distribution hitch for level towing and a rating of 4,000 lbs WD and 525 lbs WDTW.

CURT class 3 trailer hitches are typically used to attach and haul utility trailers, boat trailers, campers, snowmobile or ATV haulers and more (NOTE: Never exceed the lowest-rated towing component) Each class 3 hitch has a 2" receiver tube and is tested in accordance with SAE J684 for safety To ensure that CURT class 3 receiver hitches have what it takes for serious trailering, they are designed using a hands-on approach and are constructed with rugged, high-strength steel and precise welding.

We also protect our class 3 hitches in a co-cured finish of liquid A-coat and black powder coat for superior resistance to rust, chipping and UV damage..

Features:

  • Rated to 3,500 lbs. gross trailer weight and 525 lbs. tongue weight
  • Compatible with weight distribution hitch (4,000 lbs. WD / 525 lbs. WDTW)
  • Engineered with a vehicle-specific design for a custom fit
  • Tested for safety in accordance with SAE J684
  • Precisely welded for superior strength and fit
  • Protected by a durable high-gloss black powder coat finish
  • Co-cured in a rust-resistant liquid A-coat, inside and out
  • Equipped with an open-back receiver for easy cleaning
  • Limited lifetime warranty (one-year finish, one-year parts)
  • Made in USA (may include imported hardware)

CURT 56218 Vehicle-Side Custom 4-Pin Trailer Wiring Harness

Manufactured by: Curt

If your vehicle is not equipped with wiring for towing a trailer, CURT custom wiring is the ideal solution A custom wiring harness -- also called a T-connector -- is a simple, plug-and-play electrical device that plugs into your automotive electric system and provides a standard, universal trailer wiring connection This is done using two or more vehicle-specific, OEM-compatible connectors to plug into the taillight assembly, eliminating the need for cutting, splicing and soldering during installation.

Custom wiring harnesses are made vehicle-specific, and while they are not available for all vehicles, they do offer one of the fastest, easiest and most secure ways to wire a vehicle for towing This particular plug-in harness provides a 4-way flat connector socket and is designed to be a custom wiring harness to fit certain years of the Ford Transit Connect (to verify your vehicle compatibility, see application info) It comes with all necessary wiring components to establish a reliable trailer wiring connection, as well as a dust cover to keep the connector clean when not in use.

You have a picture in mind of your next destination -- maybe it's the boat landing at your favorite fishing spot, maybe it's a campsite that overlooks one of nature's masterpieces, or maybe it's the next big jobsite However, turning that picture into a reality takes more than just daydreaming It takes a solid connection and the right amount of power.

CURT custom wiring is made with some of the most sophisticated technology in the industry and is designed to install with ease, giving you a long-lasting electrical connection for your towing hitch setup..

Features:

  • Plugs into vehicle tail light assembly to provide a 4-way flat socket
  • Simple plug-and-play design eliminates the need for cutting or splicing
  • 4-way flat output connects tail lights, brake lights and turn signals
  • Equipped with tail light converter for vehicle-trailer compatibility
  • Constructed with SMT circuitry for better performance and durability
  • Dust cover included to keep connector clean when not in use
  • Backed by a limited one-year warranty

Hitches Near Me: We operate out of several warehouses across the country, ensuring faster delivery to your location.

Order today or call us at 877-869-6690 for expert advice and personalized service.
Default
UPC 612314024773, 612314562183
Item Weight 35.000, 1.680
Country of Manufacture US
Main Body Shape Round
Receiver Tube Size 2 IN
Finish GLOSS BLACK POWDER COAT
WC / TW (Pounds) 525 LB / 3,500 LB
WD / WDTW (Pounds) 4,000 LB / 525 LB
Weight Carrying Capacity (Pounds) 3,500 LB
WC Tongue Weight (Pounds) 525 LB
Installation Difficulty Novice, Professional
Installation Time Exact (Minutes) 30, 45
Weight Distribution (Pounds) 4,000 LB
Note 1 Trailer hitch weight ratings are limited to vehicle manufacturer's stated capacities
WD Tongue Weight (Pounds) 525 LB
Note 2 Includes installation hardware
Warranty Limited Lifetime Warranty (One-Year Finish, One-Year Parts), One-Year Limited Warranty
