Reese Trailer Tow Hitch For 11‑14 Ford Mustang V6 V8 1‑1/4" Towing Receiver Class 1
Model: 772382011 - 2014 Ford, Mustang, V6 Models
2011 - 2014 Ford, Mustang, V8 Models
Trailer Hitch Specs:
| Part Number | 77238 |
| Brand | Reese |
| Finish | Black Powdercoat |
| Class | 1 |
| Receiver size opening | 1-1/4" |
| Max gross trailer weight | 2,000 lbs |
| Max GTW w/ weight distribution | N/A |
| Max Tongue Weight | 200 lbs |
| Warranty | Lifetime |
| Installation Instructions |  |
Thank you for choosing Reese the most powerful name in towing industry bar none. Manufactured by the same people that brought you Draw-Tite and Hidden Hitch all of our products come with standard lifetime warranty and support. Our custom hitches mount easily on your Car Truck Van SUV and RV. Most applications simply bolt on without any need for drilling or modifying your bumper. Please review installation instructions manual pdf file above for exact step by step instructions. Chose Class 1 or 2 for light duty towing, chose Class 3 4 and 5 for heavy duty towing. Pair your hitch with accessories like a ball mount that is available in several drop and rise configurations. Choose a 2 inch ball to haul most standard trailers. Choose a 1-7/8" ball to tow small and u tility trailers. Our hitches come with generous tongue weight ratings for use with cargo racks and other accessories. All parts in our store are sold at a discount. If you have any questions please do not hesitate to give us a call at 702-374-8999
Partial list of fitment years: 11 12 13 14 2011 2012 2013 2014
$187 79 $293.24 36% OFF
- Best Price on Web Guarantee
- Fastest Shipping
- FREE Shipping
- In Stock
We match lower prices from major authorized retailers for brand-new products in original packaging, provided the item is in stock. The competing seller must be an authorized, professional retail business; offers from
individuals, auctions, peer-to-peer sites, or unauthorized sellers don’t qualify. Used, refurbished, or open-box items are excluded.
Please see our full terms for details.
Verify Fitment
$293.24 $187 79
Learn more
Questions? Call our Auto Experts at (877) 869-6690
Get it now, pay later
Select installments at checkout to split your purchase into 4 interest-free payments of $46.75 every 2 weeks.
- No fees, ever.
- No impact on your credit score.
Payment options are offered by Affirm and are subject to an eligibility check and might not be available in all states. CA Residents: Loans by Affirm Loan Services, LLC are made or arranged pursuant to a California Finance Lender license.
Installments in partnership with
.
Affirm and its offerings are supported in English only. Translations are not provided by Affirm.
Product Details
- Brand: Reese
- Model: 77238
- UPC: 042899076520
- Includes: Class 1 Trailer Tow Hitch
Compatibility Chart
| Year Range | Make | Model | Style |
|---|
Description
2011 - 2014 Ford, Mustang, V6 Models
2011 - 2014 Ford, Mustang, V8 Models
Trailer Hitch Specs:
| Part Number | 77238 |
| Brand | Reese |
| Finish | Black Powdercoat |
| Class | 1 |
| Receiver size opening | 1-1/4" |
| Max gross trailer weight | 2,000 lbs |
| Max GTW w/ weight distribution | N/A |
| Max Tongue Weight | 200 lbs |
| Warranty | Lifetime |
| Installation Instructions | |
Thank you for choosing Reese the most powerful name in towing industry bar none. Manufactured by the same people that brought you Draw-Tite and Hidden Hitch all of our products come with standard lifetime warranty and support. Our custom hitches mount easily on your Car Truck Van SUV and RV. Most applications simply bolt on without any need for drilling or modifying your bumper. Please review installation instructions manual pdf file above for exact step by step instructions. Chose Class 1 or 2 for light duty towing, chose Class 3 4 and 5 for heavy duty towing. Pair your hitch with accessories like a ball mount that is available in several drop and rise configurations. Choose a 2 inch ball to haul most standard trailers. Choose a 1-7/8" ball to tow small and u tility trailers. Our hitches come with generous tongue weight ratings for use with cargo racks and other accessories. All parts in our store are sold at a discount. If you have any questions please do not hesitate to give us a call at 702-374-8999
Partial list of fitment years: 11 12 13 14 2011 2012 2013 2014
Get Expert Help
Reese Trailer Tow Hitch For 11-14 Ford Mustang V6 V8 1-1/4" Towing Receiver Class 1 Install Notes
Installation Instructions for Ford Mustang (All Models)
Includes: V-6, V-6 Premium, GT 5.0 Liter, GT Premium, GT/California Special, and Shelby GT500 5.4 Liter, including Convertible Models
Part Numbers:
- 24863
- 60280
- 77238
- 24843 (U-Haul)
Wiring Access Location:
- PC3, PC4
Tools Required:
- Wrenches/Sockets: 13mm, 11/16”
- Universal Joint & Extension
- Spray Lubricant
- Drill Bits: None
Specifications:
- Max Gross Trailer Weight: 2,000 lb. (908 kg)
- Max Tongue Weight: 200 lb. (90.8 kg)
- Note: Do not exceed towing vehicle manufacturer’s rating.
Step-by-Step Instructions:
-
Lower Exhaust System:
- Remove the muffler metal tangs from the rubber exhaust hangers at the rear of the vehicle.
- Loosen the strap bolts holding the exhaust together in front of the mufflers on both sides.
- Rotate the mufflers downward for access to the round holes in the frame bottom.
-
Fishwire Carriage Bolts and Blocks:
- Insert the bolt leaders through the attachment holes in the outside of the frame and out through the large access holes at the bottom.
- Slide the bolt leader through a block and screw it onto a carriage bolt. Pull the assembly through the frame and leave the ends of the bolt leaders sticking out.
-
Position Hitch:
- Raise the hitch above the tailpipes, ensuring the hitch tubing pushes the muffler hangers upward.
- Guide the bolt leader ends through the slots in the hitch frame brackets as you raise the hitch into position.
-
Install Fasteners:
- Pull the ends of the carriage bolts through the vehicle frame and hitch brackets.
- Loosely install conical toothed washers and hex nuts. Ensure the bolts engage with the square hole in the blocks.
-
Adjust Hitch (for V-6 Models):
- Pull the hitch rearward as far as possible to allow for better muffler clearance.
-
Tighten Fasteners:
- Torque all 7/16”-14 x 1-1/2” carriage bolts to 50 Lb.-Ft. (68 N*M).
-
Reattach Exhaust System:
- Reinsert the metal muffler tangs into the rubber hangers on both sides.
- Tighten the strap bolts holding the exhaust together in front of the mufflers.
- To allow additional clearance between the hitch brackets and tailpipes, twist the mufflers and tailpipes before tightening.
Hardware List:
- (4) 7/16”-14 x 1-1/2” Carriage Bolts
- (4) Hex Nuts: 7/16”-14
- (4) 7/8” x 1-1/2” Blocks with Square Hole
- (5) 7/16” Bolt Leaders (1 extra)
- (4) Conical Toothed Washers: 7/16”
Safety Notes:
- Regularly inspect all fasteners and the hitch ball to ensure proper tightening.
- If the hitch is removed, plug all holes in the trunk pan or body panels to prevent water and exhaust fumes from entering.
- Replace any damaged hitch or ball immediately.
- Always observe safety precautions and wear eye protection when working under the vehicle.
- Do not use a torch to cut access or attachment holes.
Drawbar:
- Drawbar Kit: 3594
- Important: The drawbar must be used in the rise position only.
Compliance:
- This product complies with SAE J684, V.E.S.C. Regulation V-5, and safety requirements of the State of New York.
Additional Notes:
- Check the hitch frequently to ensure all fasteners remain tight.
- Two people may be required to raise the hitch into place to prevent the bolt leaders from being pushed back into the frame.
