Trailer Hitch Tow Package Prodigy P3 Brake Control For 21-24 Acura RDX w/ 7-Way RV Wiring 2" Drop Mount 2" Ball Class 3 2" Receiver Reese Tekonsha
-550x550.jpg "Trailer Hitch Tow Package Prodigy P3 Brake Control For 21-22 Acura RDX w/ 7-Way RV Wiring 2\" Drop Mount 2\" Ball Class 3 2\" Receiver Reese Tekonsha")
-550x550.jpg "Trailer Hitch Tow Package Prodigy P3 Brake Control For 21-22 Acura RDX w/ 7-Way RV Wiring 2\" Drop Mount 2\" Ball Class 3 2\" Receiver Reese Tekonsha")
-150x150.jpg "Trailer Hitch Tow Package Prodigy P3 Brake Control For 21-22 Acura RDX w/ 7-Way RV Wiring 2\" Drop Mount 2\" Ball Class 3 2\" Receiver Reese Tekonsha")
-150x150.jpg "Trailer Hitch Tow Package Prodigy P3 Brake Control For 21-22 Acura RDX w/ 7-Way RV Wiring 2\" Drop Mount 2\" Ball Class 3 2\" Receiver Reese Tekonsha")
- Stock: In Stock
- Brand: Reese Towpower
- Model: 84268 85343 20506 7012a 119148 21536 90195
Verify Product Fitment
This heavy duty kit is for those planning on towing a large trailer with electric brakes. This All-in-One bundle takes care of everything. No more searching and stressing out over what parts you need. This package includes the most sought after brake control on the market Tekonsha Prodigy P3. Being industries most advanced electric trailer brake control. A true proportional braking system, P3 has several added features, making it the new standard for electric trailer brake controls.
2021 - 2024 Acura, RDX, All Styles
Trailer Hitch Specs:
| Part Number | 84268 |
| Brand | Reese |
| Finish | Black Powdercoat |
| Class | 3 |
| Receiver size opening | 2" |
| Max gross trailer weight | 3,500 lbs |
| Max GTW w/ weight distribution | N/A |
| Max Tongue Weight | 350 lbs |
| Warranty | Lifetime |
| Installation Instructions |  |
Each Wiring Kit includes:
- Wiring Harness Connector (Requires Splicing)
- 4-Way to 7-Way adapter w/ mounting bracket and screws
- Wiring Kit for 6 to 8 Brake Control Systems
- Includes 25 ft. 12-2 Duplex Wire
- (2) 30 Amp Circuit Breakers
- Attaching Terminals and Ring Connectors
| Part Numbers | 119148 85343 20506 7012A |
| Brand | Tekonsha |
| Warranty | 1 Year |
| Wiring Installation |
|
| 4-Way to 7-Way Adapter Installation |
|
| Brake Control Wiring Installation |
|
The REESE Towpower starter kit provides you with everything you need to tow. Included is a ball mount with pre-torqued hitch ball, and a pin & clip. Place the draw bar in the hitch receiver tube, and secure with the pin and clip, and you're ready to go.
Ball Mount Specs:
| Part Number | 21536 |
| Brand |
Reese Towpower |
| Finish | Black Powder Coat |
| Towing Capacity |
6000 lbs |
| Tongue Weight Capacity | 600 lbs |
| Fits | 2" Reciever |
| Shank Length | 9" |
| Drop |
2" |
| Rise |
3/4" |
| Warranty | 1 Year |
P3 the industries most advanced electric trailer brake control. A true proportional braking system, P3 has several added features, making it the new standard for electric trailer brake controls.
- 5 storable setting options for pulling different trailers or preferences of multiple drivers.
- A distinct, easy-to-read LCD display with multiple screen color options.
- Up-Front controls provide easy access to all P3 features.
- Easy to understand diagnostics show output current, battery, brake, and output voltage.
- A flashing red warning system alerts user to No Trailer Brake situations.
- Select Electric over Hydraulic or Electric trailer brake mode.
- Screen information display in English, French or Spanish.
- The Original Boost feature allows for different levels of customized braking.
- Compact, dash-hugging design.
Brake Control Specs:
| Part Number | 90195 |
| Brand | Tekonsha |
| Type | Proportional |
| Axles | 1 to 4 axle trailers |
| Warranty | Lifetime |
| Installation Instructions | |
REESE Towpower custom-fit hitches are built according to manufacturer vehicle weight specifications and model year to ensure a perfect fit and top towing performance. Featuring solid all-welded construction for maximum strength and safety, every hitch meets and exceeds industry standards.
Partial list of fitment years: 21 22 23 24 2021 2022 2023 2024
Compatibility Chart:
| Year Range | Make | Model | Style |
|---|
