Trailer Tow Hitch Hardware Fastener Kit For 15‑23 Ford Mustang 1‑1/4" Towing Receiver Class 1
Model: HWKIT1(24928F)This Hitch Hardware Fastener Kit Fits The Following Vehicles:
2015 - 2023 Ford, Mustang, All Styles
(Hardware kits ships from Mexico, it can take around 3 days for the item to ship and for tracking to be posted)
This hardware kit will only work for reinstalling the following hitch part numbers from Draw-Tite Reese and Hidden Hitch: 24928 60366 77316 24469
Installation Instructions:
Questions or Comments? Call 702-374-8999
Thank you for choosing Draw Tite the most powerful name in towing industry bar none. Manufactured by the same people that brought you Reese and Hidden Hitch all of our products come with standard lifetime warranty and support. Our custom hitches mount easily on your Car Truck Van SUV and RV. Most applications simply bolt on without any need for drilling or modifying your bumper. Please review installation instructions manual pdf file above for exact step by step instructions. Chose Class 1 or 2 for light duty towing, chose Class 3 4 and 5 for heavy duty towing. Pair your hitch with accessories like a ball mount that is available in several drop and rise configurations. Choose a 2 inch ball to haul most standard trailers. Choose a 1-7/8" ball to tow small and u tility trailers. Our hitches come with generous tongue weight ratings for use with cargo racks and other accessories. All parts in our store are sold at a discount. If you have any questions please do not hesitate to give us a call at 702-374-8999
Partial list of fitment years: 15 16 17 18 19 20 21 22 23 2015 2016 2017 2018 2019 2020 2021 2022 2023
$39 59 $44.64 11% OFF
- Best Price on Web Guarantee
- Fastest Shipping
- FREE Shipping
- In Stock
We match lower prices from major authorized retailers for brand-new products in original packaging, provided the item is in stock. The competing seller must be an authorized, professional retail business; offers from
individuals, auctions, peer-to-peer sites, or unauthorized sellers don’t qualify. Used, refurbished, or open-box items are excluded.
Please see our full terms for details.
Verify Fitment
$44.64 $39 59
Learn more
Questions? Call our Auto Experts at (877) 869-6690
Get it now, pay later
Select installments at checkout to split your purchase into 4 interest-free payments of $9.75 every 2 weeks.
- No fees, ever.
- No impact on your credit score.
Payment options are offered by Affirm and are subject to an eligibility check and might not be available in all states. CA Residents: Loans by Affirm Loan Services, LLC are made or arranged pursuant to a California Finance Lender license.
Installments in partnership with
.
Affirm and its offerings are supported in English only. Translations are not provided by Affirm.
Product Details
- Brand: Draw-Tite
- Model: HWKIT1(24928F)
- Includes: Hardware Kit for Class 1 Trailer Tow Hitch
Compatibility Chart
This Hitch Hardware Fastener Kit Fits The Following Vehicles:
2015 - 2023 Ford, Mustang, All Styles
(Hardware kits ships from Mexico, it can take around 3 days for the item to ship and for tracking to be posted)
This hardware kit will only work for reinstalling the following hitch part numbers from Draw-Tite Reese and Hidden Hitch: 24928 60366 77316 24469
Installation Instructions:
Questions or Comments? Call 702-374-8999
Thank you for choosing Draw Tite the most powerful name in towing industry bar none. Manufactured by the same people that brought you Reese and Hidden Hitch all of our products come with standard lifetime warranty and support. Our custom hitches mount easily on your Car Truck Van SUV and RV. Most applications simply bolt on without any need for drilling or modifying your bumper. Please review installation instructions manual pdf file above for exact step by step instructions. Chose Class 1 or 2 for light duty towing, chose Class 3 4 and 5 for heavy duty towing. Pair your hitch with accessories like a ball mount that is available in several drop and rise configurations. Choose a 2 inch ball to haul most standard trailers. Choose a 1-7/8" ball to tow small and u tility trailers. Our hitches come with generous tongue weight ratings for use with cargo racks and other accessories. All parts in our store are sold at a discount. If you have any questions please do not hesitate to give us a call at 702-374-8999
Partial list of fitment years: 15 16 17 18 19 20 21 22 23 2015 2016 2017 2018 2019 2020 2021 2022 2023
Get Expert Help
Trailer Tow Hitch Hardware Fastener Kit For 15-23 Ford Mustang 1-1/4" Towing Receiver Class 1 Install Notes
Installation Instructions for Ford Mustang (2015-Current)
(Including Convertible Models)
Part Numbers:
- 24928
- 60366
- 77316
- 24469 (U-Haul)
Wiring Access Location:
- PC3, PC4
Tools Required:
- Ratchet
- Torque Wrench
- Safety Glasses
- Sockets: 13mm, 15mm, 11/16”
- 6” Socket Extension
Specifications:
- Max Gross Trailer Weight: 2,000 lb. (907 kg)
- Max Tongue Weight: 200 lb. (91 kg)
- Note: Do not exceed the towing vehicle manufacturer’s rating.
Installation Time:
- Standard Models: 30 minutes
- Convertible Models: Additional 60 minutes required
Step-by-Step Instructions:
-
Remove Rearward Hanger Bracket Bolts:
- Remove (2) 8mm bolts from the rearward hanger bracket on both sides of the vehicle.
- Remove (2) 8mm bolts from the forward hanger brackets.
-
Convertible Models Only:
- Remove the support member by taking off (14) 10mm bolts to access the forward hanger brackets.
-
Lower Exhaust:
- Detach the (4) hanger brackets to lower the exhaust.
- Use a ratchet strap to support the exhaust while it is lowered.
-
Install Carriage Bolts and Spacers:
- Fishwire 7/16” carriage bolts and spacers through the access hole in the frame rail.
- Pull bolts through the two bottom holes and one side hole in the frame rail, leaving fishwires attached.
-
Position Hitch:
- Lower the exhaust further using the ratchet strap if needed.
- Slide the hitch into position, ensuring side brackets are over the fishwires.
-
Secure Hitch:
- Remove fishwires and install conical washers and nuts on both sides of the hitch.
- Torque all 7/16”-14 GR5 fasteners to 50 Lb.-Ft. (68 N*M).
-
Reinstall Components:
- Reattach the hanger brackets and reinstall the M8 bolts removed earlier.
- For convertible models, reinstall the support member.
- Torque all M8 CL10.9 fasteners to 20 Lb.-Ft. (27 N*M).
- Torque all M10 fasteners to 38 Lb.-Ft. (52 N*M).
Hardware List:
- (2) Carriage Bolts: 7/16”-14 x 1.50” GR5
- (6) Spacers: 1/4” x 1” x 3”
- (6) Conical Washers: 7/16”
- (6) Hex Nuts: 7/16”-14 GR2
- (6) Fishwires: 7/16”
- (4) Carriage Bolts: 7/16”-14 x 1.25” GR5
Safety Notes:
- Regularly inspect all fasteners and the hitch ball to ensure they remain securely tightened.
- Plug all holes in the trunk pan or body panels if the hitch is removed to prevent water or exhaust fumes from entering.
- Replace any damaged hitch or ball immediately.
- Always observe safety precautions and wear eye protection while working beneath the vehicle.
- Do not cut access or attachment holes with a torch.
Drawbar:
- Drawbar Kit: 3594
- Important: The drawbar must be used in the rise position only.
Compliance:
- This product complies with SAE J684, V.E.S.C. Regulation V-5, and safety requirements of the State of New York.
Additional Notes:
- Check the hitch frequently to ensure all fasteners remain tight.
